Trance X 2

$4,699.00

Find your flow on technical trails. With adjustable geometry, the option to change rear wheel size, and a new 140mm Maestro rear suspension setup, this versatile trail bike steamrolls singletrack with confidence and control.

Size
Colour
1 in stock

Click & Collect Only

This item is Click & Collect Only from the Giant Wollongong Store at Unit 3 9-15 Ellen St and cannot be shipped.

Techs & Features

Updated suspension

A new Maestro rear suspension system gives trail riders 140mm of rear travel. The trunnion mount shock and Advanced Forged Composite rocker arm combine for a longer stroke that has a smooth, active feel, plus greater stiffness in the chassis for precision control. The rear suspension is paired with a 150mm travel fork, providing superior confidence and control on technical singletrack.

Adjustable trail geometry

A three-position Maestro flip chip lets riders dial in frame geometry for their riding style and terrain. The high setting adds more ground clearance, a good option for tight, technical terrain. In the low setting, the head tube gets slacker and the bottom bracket drops, ideal for confident handling at higher speeds. The middle position is neutral. In addition, a new headset flip chip adjusts reach so that riders can easily achieve their preferred positioning.

Rear wheel options

All models come with 29-inch front and rear wheels, but the flip chip lets you opt for a mixed wheel setup including a 27.5 rear. The stock 29-inch rear wheel optimizes stability and roll-over capabilities, while a 27.5 delivers a more agile, snappier feel and more saddle-to-tyre clearance in the rear. Some riders favor this “mullet” setup for riding steep, technical terrain.

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size. Available sizes may vary from country to country.

  • S
    163 cm 172 cm
  • M
    171 cm 180 cm
  • L
    179 cm 188 cm
  • XL
    187 cm 196 cm
Bike Geometry Diagram
Code Name S M L XL
A Seat Tube Length (mm) (inch) 400 425 450 475
A1 Seat Post Insertion Depth (mm) (inch) 280 305 330 355
B Seat Tube Angle (degrees)
C Top Tube Length (mm) (inch) 571570569 602601600 624623622 657656655
D Head Tube Length (mm) (inch) 100 105 115 125
E Head Tube Angle (degrees)
F Fork Rake (mm) (inch) 44 44 44 44
G Trail (mm) (inch) 134.1131.3128.4 134131.3128.5 133.9131.3128.5 133.9131.3128.6
H Wheelbase (mm) (inch) 119011901189 122212221221 124612461245 128112801280
I Chain Stay Length (mm) (inch) 440439438 440439438 440439438 440439438
J Bottom Bracket Drop (mm) (inch) 403530 403530 403530 403530
K Stack (mm) (inch) 617614611 621619616 631628625 640637634
L Reach (mm) (inch) 426430434 456460464 476480484 507510514
M Stand Over Height (mm) (inch) 732737742 746750755 763768773 781758790
O Stem Length (mm) (inch) 40 40 50 50
P Crank Length (mm) (inch) 165 170 170 170
Q Wheel Size

Specifications

Sizes S, M, L, XL
Colours Metallic Black
Frame ALUXX SL-Grade Aluminium front and rear triangles, 140mm Maestro suspension, 12x148mm thru-axle, 27.5 or 29-inch rear wheel compatible, flip chip - Maestro 3, flip chip - headset, integrated down tube storage
Fork Fox 36 Float Rhythm, 150mm, GRIP damper, 15x110 Kabolt X, 44mm offset
Shock Fox Float Performance, 185/52.5, custom tuned for Giant
Handlebar Giant Contact TR35, alloy, 20mm rise
Grips Giant Tactal Pro Single Lock-On, 132x35mm
Stem Giant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm
Seatpost Contact Switch AT dropper, remote S: 110-140mm travel / 30.9 x 395mm M: 140-170mm travel / 30.9 x 470mm L: 170-200mm travel / 30.9 x 530mm XL: 170-200mm travel / 30.9 x 530mm
Saddle Giant Romero
Pedals N/A
Shifters Shimano Deore, 1x12
Front derailleur N/A
Rear derailleur Shimano Deore, Shadow +
Brakes Shimano BR-MT420, hydraulic, four piston, Shimano RT-66 rotors [F]203mm, [R]180mm
Brake levers Shimano Deore BL-MT401
Cassette Shimano Deore M6100, 10x51
Chain KMC X-12
Crankset Praxis Cadet HD M24, 30t, 55mm chainline S:165mm, M:170mm, L:170mm, XL:170mm
Bottom bracket Praxis, press fit
Rims Giant AM Tubeless ready Alloy 29, 30mm inner width
Hubs [F] Giant Boost 110x15, Sealed [R] Giant Boost148x12, Sealed Bearing, HG
Spokes Sapim Race
Tires [F] Maxxis Minion DHF, 29x2.5 WT, 60 tpi, EXO, TR [R] Maxxis Dissector 29x2.4 WT, 60 tpi, EXO TR, tubeless
Extras Tubeless prepared, 2.5" max tyre size, 34t max chainring size, 3M tailgate protector, down tube and chainstay protection
Weight The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Please note that our specifications may be impacted by running substitution changes, we highly recommend confirming the specifications of our products with your local retailer at the time of sale if purchasing in-store. *Recommended Retail Prices are subject to change without notice and may vary from store to store depending on freighting and assembly costs.
