Revolt 2

$1,899.00

Ride roads, gravel or dirt with this versatile aluminium all-rounder. A composite fork gives it a smooth ride, and a flip chip lets you adjust wheelbase and tyre clearance.

Size
Colour

Click & Collect Only

This item is Click & Collect Only from the Giant Wollongong Store at Unit 3 9-15 Ellen St and cannot be shipped.

Revolt 2 - Lg / Asphalt green is available from our supplier warehouse. Our team will call you when we receive your order to confirm the arrival date - usually 7-10 days.

Techs & Features

Confident handling

Frame is designed with endurance positioning and shorter chainstays for precise handling, agility and control. A longer reach, shorter stem and lower bottom bracket drop improves stability on rugged terrain.

Tuned compliance

Dropped seatstays with thin tubing absorb road shocks and vibrations. The D-Fuse handlebar and seatpost work as a system to add compliance without sacrificing stiffness while cornering, sprinting or climbing.

Adaptable to the terrain

A flip chip on the rear dropout adjusts the wheelbase: short for quicker handling and acceleration, or long for improved stability at speed. The long setting allows for larger diameter tyres up to 53mm. You can choose the included D-Fuse seatpost for maximum compliance, or switch to a 30.9mm round or dropper post.

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size. Available sizes may vary from country to country.

  • XS
    155 cm 166 cm
  • S
    159 cm 171 cm
  • M
    169 cm 181 cm
  • ML
    174 cm 186 cm
  • L
    179 cm 191 cm
  • XL
    189 cm 200 cm
Bike Geometry Diagram
Code Name XS S M ML L XL
A Seat Tube Length (mm) (inch) 430 450 470 490 510 530
B Seat Tube Angle (degrees)
C Top Tube Length (mm) (inch) 540 550 560 575 585 600
D Head Tube Length (mm) (inch) 125 135 150 165 180 195
E Head Tube Angle (degrees)
F Fork Rake (mm) (inch) 50 50 50 50 50 50
G Trail (mm) (inch) 7882 7275 6872 6568 6568 6568
H Wheelbase (mm) (inch) 10291039 10251035 10301040 10351045 10451055 10611071
I Chain Stay Length (mm) (inch) 430440 430440 430440 430440 430440 430440
J Bottom Bracket Drop (mm) (inch) 8081 8081 8081 8081 8081 8081
K Stack (mm) (inch) 556 570 586 602 616 630
L Reach (mm) (inch) 381 381 387 391 397 407
M Stand Over Height (mm) (inch) 717724 734741 752759 769776 786793 801810
O Stem Length (mm) (inch) 50 60 70 80 80 90
P Crank Length (mm) (inch) 170 170 172.5 172.5 175 175
Q Wheel Size

Specifications

Sizes XS, S, M, M/L, L, XL
Colours Asphalt Green
Frame ALUXX-Grade Aluminium, 12x142mm thru-axle, disc, flip chip dropout
Fork Advanced-Grade Composite, full-composite OverDrive steerer, 12mm thru-axle, disc
Handlebar Giant Contact XR Ergo-Control, 31.8mm XS:4cm, S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
Grips Cork tape with gel
Stem Giant Sport, 8-degree XS:50mm, S:60mm, M:70mm, M/L:80mm, L:80mm, XL:90mm
Seatpost Giant D-Fuse, alloy, 14mm offset
Saddle Giant Approach
Pedals N/A
Shifters Shimano Sora, 2x9
Front derailleur Shimano Sora
Rear derailleur Shimano Sora, long cage
Brakes Tektro MD-C550 mechanical, Giant MPH rotors [F]160mm, [R]160mm
Brake levers Shimano Sora
Cassette Shimano HG400, 11x34
Chain KMC X9
Crankset FSA Vero Pro, 32/48 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
Bottom bracket Cartridge
Rims Giant S-X2 Disc wheelset, alloy
Hubs Giant alloy, 12mm thru-axle
Spokes Stainless
Tires Giant CrossCut AT 2, 700x38c, tubeless
Extras Tubeless prepared, 53mm max tyre size in "long" flip chip position, 45mm max tyre size in "short" flip chip position
Weight The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Please note that our specifications may be impacted by running substitution changes, we highly recommend confirming the specifications of our products with your local retailer at the time of sale if purchasing in-store. *Recommended Retail Prices are subject to change without notice and may vary from store to store depending on freighting and assembly costs.
