Reign Advanced

$8,999.00
Tax included
Go fast, get rowdy and nail new lines. Developed with Giant's enduro racing pros, this full-composite machine pairs a 29-inch front wheel with a 27.5-inch rear, 160mm of Maestro rear suspension and adjustable geometry.
Size
Colour

Click & Collect Only

This item is Click & Collect Only from the Giant Wollongong Store at Unit 3 9-15 Ellen St and cannot be shipped.

Orders from the Giant Warehouse take approximately 7-10 business days to arrive in store.

Techs & Features

Race-bred suspension

A Maestro rear suspension system with 160mm of travel, paired with a 170mm fork, was developed and tested under the extreme conditions of Enduro World Series races. The trunnion mount shock has a longer stroke (62.5mm compared to 60mm on the previous generation). And the Advanced Forged Composite upper rocker arm adds stiffness and lowers overall weight.

Adjustable enduro geometry

Flip chip technology lets you switch between three settings depending on the terrain and riding style. Choose Low, Mid or High to adjust head and seat tube angles, bottom bracket drop, reach and other key geometry. This gives you three distinct setups to fine-tune handling, from planted stability to a more responsive ride feel.

Mixed-Wheel Agility

A 29-inch front wheel rolls confidently through rough terrain and delivers stability at speed, while the 27.5-inch rear wheel adds agility and a more responsive feel. This purpose-built mixed-wheel setup helps the Reign Advanced stay composed on fast, technical terrain while remaining quick and manoeuvrable through tight sections.

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size. Available sizes may vary from country to country.

  • S
    163 cm 172 cm
  • M
    171 cm 180 cm
  • L
    179 cm 188 cm
  • XL
    187 cm 198 cm
Bike Geometry Diagram
Code Name S M L XL
A Seat Tube Length (mm) (inch) 400 425 450 475
A1 Seat Post Insertion Depth (mm) (inch) 262 287 312 337
B Seat Tube Angle (degrees)
C Top Tube Length (mm) (inch) 558 | 557 | 556 589 | 588 | 587 622 | 621 | 621 654 | 653 | 653
D Head Tube Length (mm) (inch) 100 105 115 120
E Head Tube Angle (degrees)
F Fork Rake (mm) (inch) 44 44 44 44
G Trail (mm) (inch) 147 | 144 | 141 147 | 144 | 141 147 | 144 | 141 147 | 144 | 141
H Wheelbase (mm) (inch) 1214 | 1213 | 1212 1246 | 1245 | 1244 1271 | 1270 | 1269 1304 | 1303 | 1302
I Chain Stay Length (mm) (inch) 445 | 443 | 442 445 | 443 | 442 445 | 443 | 442 445 | 443 | 442
J Bottom Bracket Drop (mm) (inch) 29 | 24 | 19 29 | 24 | 19 29 | 24 | 19 29 | 24 | 19
K Stack (mm) (inch) 633 | 630 | 627 638 | 635 | 632 647 | 644 | 641 652 | 649 | 646
L Reach (mm) (inch) 418 | 421 | 426 448 | 452 | 456 468 | 471 | 476 499 | 503 | 507
M Stand Over Height (mm) (inch) 714 | 718 | 723 733 | 738 | 742 746 | 750 | 755 762 | 766 | 771
O Stem Length (mm) (inch) 40 40 40 40
P Crank Length (mm) (inch) 165 170 170 170
Q Wheel Size 29" [F] 27.5" [R] 29" [F] 27.5" [R] 29" [F] 27.5" [R] 29" [F] 27.5" [R]

Specifications

Sizes S, M, L, XL
Colours Luminous Lagoon
Frame Advanced-Grade Composite front and rear triangles, 160mm Maestro suspension, flip chip 3 position, 12x148mm thru-axle, 27.5 or 29-inch rear wheel compatible, integrated downtube storage, 55mm Chainline
Fork RockShox Zeb Ultimate Charger 3.2, 170mm,15x110mm Maxle Stealth thru-axle
Shock RockShox Vivid Ultimate RCT2, 2 position, custom tuned for Giant
Handlebar Giant Contact TR35, alloy, 35mm rise
Grips Giant Tactal Pro Single lock-on
Stem Giant Contact SL 35 S:40mm, M:40mm, L:40mm, XL:40mm
Seatpost Giant Contact Switch AT dropper, adjustable travel, remote S: 110-140mm travel / 30.9 x 395mm M: 140-170mm travel / 30.9 x 470mm L: 170-200mm travel / 30.9 x 530mm XL: 170-200mm travel / 30.9 x 530mm
Saddle Giant Romero SL
Pedals N/A
Shifters SRAM AXS Pod, 1x12
Rear derailleur SRAM GX Eagle Transmission AXS
Brakes TRP EVO Pro, hydraulic, TRP 2.3mm rotors [F]203mm, [R]180mm
Brake levers TRP EVO Pro
Cassette SRAM XS-1275, Transmission, 10x52
Chain SRAM GX Transmission
Crankset SRAM GX Transmission, 32t, 55mm chainline S:165mm, M:165mm, L:165mm, XL:165mm
Bottom bracket SRAM DUB, press fit
Rims Giant TRA Hookless Tubeless ready Alloy Fr: 29", Rr: 27.5" 30mm inner width
Hubs [F] Giant TRA MTB Alloy Hub, 6 Bolt, 28H [R] Giant TRX MTB Alloy Hub, SRAM XD Drive Body Pawl Driver (Pawl 36x2 T), 28H
Spokes Sapim Laser
Tyres [F] Maxxis Assegai 29x2.5 WT, MaxxTerra, EXO+, TR [R] Maxxis Minion DHR II 27.5x2.4 WT, MaxxTerra, DD, TR tubeless
Extras Tubeless prepared, MRP AMG chain guide
Max tyre clearance 2.5"
Max chainring size 36t
Weight The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Please note that our specifications may be impacted by running substitution changes, we highly recommend confirming the specifications of our products with your local retailer at the time of sale if purchasing in-store. *Recommended Retail Prices are subject to change without notice and may vary from store to store depending on freighting and assembly costs.
