STP 24 Liv

$1,499.00

Tax included

For young riders ready to level up their skills, the STP 24 delivers the perfect mix of stability, control, and fun. With youth-tuned suspension, balanced geometry, and components built for smaller riders, it helps them flow through corners, jump higher, and push their limits with confidence—on trails, pump tracks, and everything in between.

Colour

alpine green

Product variants

Techs & Features

BUILT TO LAST

The ALUXX-grade aluminium frame and Crest TR Comp Lite 100mm suspension fork are engineered to handle rough rides while keeping things smooth and controlled. The 24-inch TRA 2 WheelSystem with Wide Guard rim technology lets riders run lower tyre pressures for added traction without sacrificing rim durability.

YOUTH-TUNED CONTROL

Designed for riders 125–145cm tall, the STP 24 features youth-specific components that ensure proper fit and control. The narrower handlebars, Liv Grit Core Lite saddle, and Contact Switch AT Lite dropper seatpost provide a comfortable, secure riding position, while youth-tuned hydraulic disc brakes offer smooth, reliable stopping power across all terrain.

TRICK-READY HANDLING

With 24-inch wheels, front and rear thru-axles, and a short rear center, the STP 24 feels agile yet stable. Its low center of gravity makes it easier to lift the front wheel, pump through rollers, and carve corners with confidence and control.

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size. Available sizes may vary from country to country.

One Size

125 cm 145 cm

Name	One Size
A Seat Tube Length (mm) (inch)	300	11.8
A1 Seat Post Insertion Depth (mm) (inch)	250	9.8
B Seat Tube Angle (degrees)	73.0°
C Top Tube Length (mm) (inch)	523	20.6
D Head Tube Length (mm) (inch)	90	3.5
E Head Tube Angle (degrees)	67.0°
F Fork Rake (mm) (inch)	30	1.2
G Trail (mm) (inch)	104	4.1
H Wheelbase (mm) (inch)	975	38.4
I Chain Stay Length (mm) (inch)	375	14.8
J Bottom Bracket Drop (mm) (inch)	40	1.6
K Stack (mm) (inch)	534	21
L Reach (mm) (inch)	360	14.2
M Stand Over Height (mm) (inch)	629	24.8
O Stem Length (mm) (inch)	40	1.6
P Crank Length (mm) (inch)	140	5.5

Specifications

Sizes One size

Colours Alpine Green

Frame ALUXX-grade aluminium, 12x142mm thru-axle

Fork Crest TR Comp 24", Travel 100mm, 34mm stanchion, alloy steerer, youth tuned, 15x110 TA

Shock N/A

Handlebar Giant Sport, alloy, 31.8 mm, 640 mm

Grips Giant Junior

Stem Forged alloy, 0-degree

Seatpost Giant Contact Switch AT Lite, adjustable travel, remote 70-100mm travel / 30.9 x 315mm

Saddle Liv Grit Core

Pedals Platform

Shifters microSHIFT Advent, 1x9

Front derailleur N/A

Rear derailleur microSHIFT Advent, 1x9

Brakes Tektro HD-J2820 hydraulic [F]180mm, [R]160mm rotors

Brake levers Tektro HD-J2820

Cassette Shimano HG93, 11x38

Chain KMC X9

Crankset Prowheel Forged, 30t, 140mm

Bottom bracket Cartridge threaded

Rims Giant TRA 2 Hookless Tubeless ready Alloy, 30mm inner width

Hubs [F] Giant Tracker, thru-axle, 6-bolt [R] Giant Tracker thru-axle, 6-bolt, HG driver body

Spokes Stainless, 14g

Tyres Kenda Amrak, 24x2.2"

Weight The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Please note that our specifications may be impacted by running substitution changes, we highly recommend confirming the specifications of our products with your local retailer at the time of sale if purchasing in-store. *Recommended Retail Prices are subject to change without notice and may vary from store to store depending on freighting and assembly costs.
