Trance X 3

$3,399.00 $4,499.00

Float through rock gardens, hit the jumps, and find the faster line. With quick-handling 27.5 wheels and adjustable frame geometry, this lively trail bike is a party on wheels.

Size
Colour
1 in stock

Click & Collect Only

This item is Click & Collect Only from the Giant Wollongong Store at Unit 3 9-15 Ellen St and cannot be shipped.

Techs & Features

Adjustable frame geometry

New flip chip feature lets you change the headtube and seattube angles, as well as the bottom bracket height, to fine-tune handling for varying trail conditions and individual riding style.

27.5 agility and control

27.5-inch wheels balance agility and control, giving you the ability to roll over rugged terrain, flick the bike at speed, change lines, and explode out of corners.

Progressive suspension

Updated Maestro rear suspension features a trunnion mount shock with a longer stroke and smoother feel. With 145mm of rear travel (and 160mm up front), it has an Advanced Forged Composite upper rocker arm for increased stiffness and strength plus lower overall frame weight.

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size. Available sizes may vary from country to country.

  • S
    163 cm 172 cm
  • M
    171 cm 180 cm
  • L
    179 cm 188 cm
  • XL
    187 cm 196 cm
Bike Geometry Diagram
Code Name S M L XL
A Seat Tube Length (mm) (inch) 420 430 465 496
B Seat Tube Angle (degrees)
C Top Tube Length (mm) (inch) 562560 595593 622620 649647
D Head Tube Length (mm) (inch) 95 105 115 125
E Head Tube Angle (degrees)
F Fork Rake (mm) (inch) 37 37 37 37
G Trail (mm) (inch) 138132 138132 138132 138132
H Wheelbase (mm) (inch) 11791177 12031202 12331231 12621260
I Chain Stay Length (mm) (inch) 433430 433430 433430 433430
J Bottom Bracket Drop (mm) (inch) 3020 3020 3020 3020
K Stack (mm) (inch) 596590 605599 614608 623617
L Reach (mm) (inch) 427435 447455 472480 497505
M Stand Over Height (mm) (inch) 709718 714723 740750 762772
O Stem Length (mm) (inch) 40 40 50 50
P Crank Length (mm) (inch) 165 170 170 170
Q Wheel Size

Specifications

Sizes S, M, L, XL
Colours Good Grey / Black
Frame ALUXX SL-Grade aluminium front and rear triangles, 145mm Maestro suspension, flip chip, UDH hanger, 12x148mm thru-axle, 55mm Chainline
Fork RockShox Yari RC, Motion Control, DebonAir, 37mm offset, 160mm, 15x110 Stealth, custom tuned for Giant
Shock Fox Float DPS Performance, custom tuned for Giant
Handlebar Giant Contact TR35, alloy, 35mm
Grips Giant Tactal Pro Single lock-on
Stem Giant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm
Seatpost Giant Contact Switch dropper, remote S: 125mm travel / 30.9 x 395mm M: 150mm travel / 30.9 x 440mm L: 170mm travel / 30.9 x 450mm XL: 170mm travel / 30.9 x 450mm
Saddle Giant Romero
Pedals N/A
Shifters Shimano Deore, 1x12
Front derailleur N/A
Rear derailleur Shimano Deore
Brakes Shimano Deore BR-MT420, hydraulic, Shimano RT-66 rotors [F]203mm, [R]180mm
Brake levers Shimano BL-MT401
Cassette Shimano Deore, 10x51
Chain KMC X-12
Crankset Praxis Cadet M24 HD, 32t S:165mm, M:170mm, L:170mm, XL:170mm, 55mm chainline
Bottom bracket Praxis, press fit
Rims Giant AM 27.5, alloy
Hubs Alloy, sealed bearing
Spokes Sapim
Tires [F] Maxxis Assegai 27.5x2.6, 3C MaxxTerra, EXO, TR [R] Maxxis Minion DHRII 27.5x2.6, 3C MaxxTerra, EXO, TR, tubeless
Extras Tubeless prepared, 2.6" max tyre size, 34t max chainring size
Weight The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Please note that our specifications may be impacted by running substitution changes, we highly recommend confirming the specifications of our products with your local retailer at the time of sale if purchasing in-store. *Recommended Retail Prices are subject to change without notice and may vary from store to store depending on freighting and assembly costs.
